Limestone / Granite Jaw Crusher Machine 210mm Max Feeding Size
Characteristic And Uses
This machine adopts newest standard which optimized designed by the computer. And enjoys the advantages of simple structure, high yield, low energy convenient use, etc And it is the present domestic most advanced type suitable for various mineral and rock for rough and middle crush work with the compressive strength below 250 Mpa.
| Name | Limestone / Granite Jaw Crusher Machine 210mm Max Feeding Size |
| Model | Jaw Crusher Machine |
| Certification | Mining Machine |
Technical Specifications and Performance
| Basic parameters | Inlet port width mm | Inlet port length mm | Maximum feeding size mm | Discharge port adjustment range mm | Production capacity t/h | Motor Power kw | Machine Weight t | Dimensions mm |
| PE250x400 | 250 | 400 | 210 | 20-60 | 4-14 | 15 | 3 | 1450X1350X1400 |
| PE250X500 | 250 | 500 | 210 | 20-60 | 5-16 | 18.5 | 4.1 | 1320x1400x1320 |
| PE400X600 | 400 | 600 | 340 | 35-85 | 8-25 | 30 | 6.95 | 1700x1800x1650 |
| PE500X750 | 500 | 750 | 425 | 50-100 | 30-70 | 55 | 10.5 | 2118x1962x1843 |
| PE600X900 | 600 | 900 | 500 | 75-125 | 40-100 | 75 | 20 | 2600x2180x2325 |
| PE750X1060 | 750 | 1060 | 630 | 80-140 | 80-180 | 95 | 25.5 | 2550x2322x3110 |
| PE900X1200 | 900 | 1200 | 750 | 95-165 | 200-290 | 110 | 49.5 | 3110x3026x3280 |
| PE1200x1500 | 1200 | 1500 | 950 | 160-280 | 300-500 | 200 | 88 | 4590x3272x4033 |
| PEX150X750 | 150 | 750 | 120 | 15-45 | 5-14 | 15 | 3 | 1194x1531x1089 |
| PEX250X750 | 250 | 750 | 210 | 25-60 | 8-15 | 30 | 4.98 | 1520x1750x1270 |
| PEX250X1000 | 250 | 1000 | 210 | 25-60 | 10-25 | 30 | 6.34 | 1530x1992x1380 |
| PEX250X1200 | 250 | 1200 | 210 | 20-60 | 30-52 | 45 | 9.5 | 2300x2120x1500 |
Company introduction
Tangshan Mine Machinery Factory is a specialized manufacturer that produces complete sets of equipment for metallurgy, mining, building materials, environmental protection, as well as the design and manufacture of complete sets of sand and gravel materials, and the design and manufacture of dry tailings discharge. The company was founded in 1971 and turned into a joint-stock enterprise in 1997.
We are a member of the China Heavy Machinery Association, a member of the Crushing and Grinding Association, a member of the Mining Machinery Association, and a member of the China Building Materials Machinery Association. We have participated in the formulation of a number of equipment manufacturing standards.
The company's principles are: First-class talents, First-class management, First-class machine, First-class quality, First-class honor.
Sincerely hope to reach friendly cooperation with you.
FAQ to save your precious time!
Q1: Hi, are you a mining machinery manufacturer?
Answer: Yes, we are a professional manufacturer of mining machine. Our company welcomes customers to visit our factory at any time.
Q2: How long is the warranty period of your equipment? Does your company provide spare parts?
Answer: The warranty period of our machine is one year. For those wearing parts, we guarantee to provide high-quality parts for a long time.
Q3: How long does it take to deliver?
Answer: Production usually starts after receiving the advance payment. Small machine is guaranteed to be delivered within one month. Large-scale machine is guaranteed to be delivered within 2-3 months.
Q4: Do you provide machine operation guidance?
Answer: Yes. We have professional engineers for installation, commissioning and operation guidance.
